    5050 RGBCW Flexible LED Strip Lights 60 LED/M 19.2Watts 4 In 1 SMD Light Strip

    Ask Lasest Price
    Brand Name : Phenson
    Model Number : PS50RGBCW24060IP20
    Certification : CE,ROHS
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 10,0000m
    Delivery Time : 7~10 days
    • Product Details
    • Company Profile

    5050 RGBCW Flexible LED Strip Lights 60 LED/M 19.2Watts 4 In 1 SMD Light Strip

    5050RGBCW Flexible LED Strip Lights 60LED/M 19.2Watts 4in1 SMD light strip


    Feature

    1) LED chip——SMD5050 R, G, B, W(WW/CW) 4 in 1 LED chip.

    2)Standard Reel Length: 5meter/roll, also can be customized.

    3)Cutted: you can cut this stuff pretty easily with wire cutters,

    Solder to the 0.1'' copper pads and you're good to go.

    DC12V: cuttable per 3LED, there are cut-lines every 5cm.

    DC24V: cuttable per 6LED, there are cut-lines every 10cm.

    4)Power consumption: theory power is 19.2W/M, but the really power just about 12W/M.

    5)Power supply used:

    DC12V led strip: you must use a 12V DC power supply to power this strip, do not use higher than 13V,

    DC24V led strip: please use 24V DC power supply, or you can destroy the entire strip.

    6)Adhesive tape: non-waterproof: with 3M adhesive on back side for sticky;

    waterproof: screw+silicon clip, or 3M adhesive back side.

    7)Type: RGBW, RGBCW, RGBWW——60LEDs/m, White PCB

    9)Color temperature:

    RGBWW: RGB+3000K;

    RGBW: RGB+6000K;

    RGBCW: RGB+10000K


    Product description:

    DC24V, 5050 RGB , 60 LEDs/m

    Product:5050 DC24V strip

    Dimension: L5000mm*W10 mm*H0.25mm

    LED quantity: 300 SMDs/pcs, 60 5050 RGBCW SMDs/m

    Thickness of PCB: 0.25mm

    Working voltage: DC24V

    Power dissipation: 19.2W/m

    Working current: 4A/reel, 6led cuttable(DC24V)

    Viewing angle: 120 degree

    Packing: 5m/reel

    Color: RGBW

    Color of PCB: white


    Product specification:

    Ordering CodeColors AvailableLED featuresLED
    Q’ty/m
    PCBVoltage
    (VDC)
    Max Power
    (W/m)
    Waterproof Grade available (IP)
    PS50RGBCW24060IP20RGBCWSanan5050 3000-3500mcd6012mm white24VDC19.2

    IP20




    Application:
    -Indoors or semi-outdoors using as decorative lighting for festivals, events, shows.
    -Back or edge lighting for signage
    -Architectural lighting for canopy, corridor, window, archway.
    -Path or contour making, etc.
