3535 PLCC6 Series White Color SMD Light Emitting Diode Automative
Exterior Application
Feature :
1. Dimension(length*width*height: mm): 3.5* 3.5* 1.9 mm
2. White ,red ,yellow color
3. Good ight color consistency , high color gamut
4. High lighting efficiency, high brightness, high current drive
5. Lead-free package, Rohs certificate
6. Electrostatic Discharge Withstand Voltage Level ≥2000V /
≥8000V(ESD Protection Device).
7. Package 3000pcs/reel
8. PCT lead frame
9. Moisture Sensitivity Level.2
10 Primer process for the gold plating has sulphide protection.
11. High heat resistance, low thermal resistance, high reliability
Package Dimmension :
Application :
1. CHMSL,,DRL,Fog Lamp,Reverse Lamp.
2. TSL(Front/Rear)
3. DRL,Fog Lamp,Reverse Lamp.
Description :
The product qualification test plan is based on the guidelines of
AEC‐Q101 Stress Test Qualification for Automotive Grade Discrete
Semiconductors ,follow TS16949.
Parameter :
| Part No. | lm | X/Y/WD(nm) | Vf(V) | If (mA) | View angle |
| RF-OMRA35TS-AA-J | 24 | 620 | 2.2 | 150 | 120° |
| RF-YMRA35TS-AA-J | 24 | 592 | 2.2 | 150 | 120° |
| RF-WMRA35DS-AA-J | 70 | (0.33,0.34) | 3 | 150 | 120° |
Note:
1. 1/10 Duty cycle, 0.1ms pulse width.
2. The above forward voltage measurement allowance tolerance is
0.1V.3
3. The below color coordinates measurement allowance tolerance is
0.003.
4. the above luminous flux measurement allowance tolerance ±10%.
5. Care is to be taken that power dissipation does not exceed the
absolute maximum rating of the product.
6. All measurements were made under the standardized environment of
Refond.
7.When the LEDs are in operation the maximum current should be
decided after measuring the package temperature,junction
temperature should not exceed the maximum rate.LED
