    Addressable RGBW 35*25mm LED Pixel DC5V 4w LED Christmas Light

    Ask Lasest Price
    Brand Name : Phenson
    Model Number : PS-032001MA4SD6
    Certification : CE,ROHS
    Price : Negotiable
    Payment Terms : Western Union, T/T, Paypal
    Supply Ability : 500,000
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Addressable RGBW 35*25mm LED Pixel DC5V 4w LED Christmas Light

    Addressable RGBW 35*25mm LED Pixel DC5V 4w Led Christmas Light​


    Specification,

    Item TypeAddressable led module
    Model NumberPS-032001MA4SD6
    Light SourceLED
    Lighting solutions serviceLighting and circuitry design
    Input Voltage(V)DC5V
    Lamp Luminous Flux(lm)R: 51lm G: 76lm B: 20lm W:102lm
    Working Temperature(℃)- 40 ~ 50 ℃
    Working Lifetime(Hour)50000
    IP RatingIP65
    Emitting ColorRGBW
    Place of OriginGUA
    Brand NamePhensonlighting
    ApplicationTheme Park
    Color Temperature(CCT)RGBW
    Warranty(Year)2-Year
    Light SourceImitation lumen lamp beads
    Beam Angle140°
    ControlSPI / SM16714
    PCB colorBlack
    Size (mm)35*25


    Product Description

    This is a super bright RGBW LED mounted on a Aluminum
    board backside without a 3M stick ,suggested to install on
    any plate for heat disspation,2 pcs M3 mounting hole on
    each conner WS2811 control ,it's working with any SPI controller or a DMX decoder
    constant voltage working, there are 3 pads on each
    side of board do not confuse the Data in and Data out
    each module contains a pair of JST connector and packed by An-ti static bag


    Pictures,
